[PATCH] mtd: spi-nor: implement ASP lock for S25FL512S
Christoph Reiter
christoph.reiter at evk.biz
Mon Aug 25 07:59:05 CEST 2025
This implements the locking mechanism used for protecting individual
sectors of Spansion/Infineon S25FL512S chips. This might be applicable to other chips of this series,
but I don't have the hardware to test it.
Signed-off-by: Christoph Reiter <christoph.reiter at evk.biz>
---
drivers/mtd/spi/sf_internal.h | 1 +
drivers/mtd/spi/spi-nor-core.c | 163 +++++++++++++++++++++++++++++++++
drivers/mtd/spi/spi-nor-ids.c | 4 +-
include/linux/mtd/spi-nor.h | 2 +
4 files changed, 168 insertions(+), 2 deletions(-)
diff --git a/drivers/mtd/spi/sf_internal.h b/drivers/mtd/spi/sf_internal.h
index 8d2249ce354..319f4840cd6 100644
--- a/drivers/mtd/spi/sf_internal.h
+++ b/drivers/mtd/spi/sf_internal.h
@@ -69,6 +69,7 @@ struct flash_info {
#define SPI_NOR_HAS_SST26LOCK BIT(15) /* Flash supports lock/unlock via BPR */
#define SPI_NOR_OCTAL_READ BIT(16) /* Flash supports Octal Read */
#define SPI_NOR_OCTAL_DTR_READ BIT(17) /* Flash supports Octal DTR Read */
+#define SPI_NOR_HAS_ASP_LOCK BIT(18) /* Flash supports Advanced sector protection */
};
extern const struct flash_info spi_nor_ids[];
diff --git a/drivers/mtd/spi/spi-nor-core.c b/drivers/mtd/spi/spi-nor-core.c
index 76c33b24368..8821afeda99 100644
--- a/drivers/mtd/spi/spi-nor-core.c
+++ b/drivers/mtd/spi/spi-nor-core.c
@@ -1553,6 +1553,158 @@ static int stm_is_unlocked(struct spi_nor *nor, loff_t ofs, uint64_t len)
return stm_is_unlocked_sr(nor, ofs, len, status);
}
#endif /* CONFIG_SPI_FLASH_STMICRO */
+
+
+/* Advanced Sector Protection for S25FL512S */
+
+#define ASP_DYB_LOCKED 0x0
+#define ASP_DYB_UNLOCKED 0xff
+
+static int _asp_check_params(struct spi_nor *nor, loff_t ofs, uint64_t len)
+{
+ if (ofs + len > nor->size) {
+ dev_err(nor->dev, "Params exceed length of flash\n");
+ return -1;
+ }
+ return 0;
+}
+
+static int _asp_read_dyb(struct spi_nor *nor, loff_t ofs)
+{
+ u8 buf;
+ int ret;
+ struct spi_mem_op op = SPI_MEM_OP(SPI_MEM_OP_CMD(SPINOR_ASP_DYBRD, 0),
+ SPI_MEM_OP_ADDR(4, ofs, 0), /* 4 address bytes */
+ SPI_MEM_OP_NO_DUMMY,
+ SPI_MEM_OP_DATA_IN(1, &buf, 0)); /* read 1 byte */
+ spi_nor_setup_op(nor, &op, nor->reg_proto);
+ op.data.dir = SPI_MEM_DATA_IN;
+ ret = spi_mem_exec_op(nor->spi, &op);
+ if (ret) {
+ debug("%s: spi_mem_exec_op() ret %d\n", __func__, ret);
+ return ret < 0 ? ret : -1;
+ }
+ return buf;
+}
+
+static int _asp_write_dyb(struct spi_nor *nor, loff_t ofs, u8 value)
+{
+ int ret;
+ struct spi_mem_op op = SPI_MEM_OP(SPI_MEM_OP_CMD(SPINOR_ASP_DYBWR, 0),
+ SPI_MEM_OP_ADDR(4, ofs, 0), /* 4 address bytes */
+ SPI_MEM_OP_NO_DUMMY,
+ SPI_MEM_OP_DATA_OUT(1, &value, 0)); /* write 1 byte */
+ spi_nor_setup_op(nor, &op, nor->reg_proto);
+ op.data.dir = SPI_MEM_DATA_OUT;
+
+ write_enable(nor);
+
+ ret = spi_mem_exec_op(nor->spi, &op);
+ if (ret) {
+ debug("%s: spi_mem_exec_op() ret %d\n", __func__, ret);
+ return ret < 0 ? ret : -1;
+ }
+
+ ret = spi_nor_wait_till_ready(nor);
+ if (ret) {
+ debug("%s: spi_nor_wait_till_ready() ret %d\n", __func__, ret);
+ return ret < 0 ? ret : -1;
+ }
+
+ write_disable(nor);
+ return 0;
+}
+
+static int asp_is_unlocked(struct spi_nor *nor, loff_t ofs, uint64_t len)
+{
+ int ret;
+ loff_t sec_first = ofs & ~(nor->sector_size - 1);
+ loff_t sec_last = (ofs + len - 1) & ~(nor->sector_size - 1);
+
+ /* Iterate over sectors */
+ for (loff_t sec = sec_first; sec <= sec_last; sec += nor->sector_size) {
+ /* Read DYB byte of that sector */
+ ret = _asp_read_dyb(nor, sec);
+ if (ret < 0) {
+ /* Error while reading DYB */
+ debug("%s: _asp_read_dyb() ret %d\n", __func__, ret);
+ return ret;
+ }
+ debug("%s: sector %llx=%x\n", __func__, sec, ret);
+ if (ret == ASP_DYB_LOCKED) {
+ /* At least 1 sector locked - return immediately */
+ return 0;
+ }
+ }
+ return 1;
+}
+
+static int asp_lock(struct spi_nor *nor, loff_t ofs, uint64_t len)
+{
+ int ret;
+ loff_t sec_first, sec_last;
+
+ if (_asp_check_params(nor, ofs, len)) {
+ return -1;
+ }
+ if (!len) {
+ return 0;
+ }
+ sec_first = ofs & ~(nor->sector_size - 1);
+ sec_last = (ofs + len - 1) & ~(nor->sector_size - 1);
+
+ /* Iterate over sectors */
+ for (loff_t sec = sec_first; sec <= sec_last; sec += nor->sector_size) {
+ /* Skip if already locked */
+ if (!asp_is_unlocked(nor, sec, nor->sector_size)) {
+ debug("%s: sector %llx already locked\n", __func__, sec);
+ continue;
+ }
+ /* Lock the sector */
+ ret = _asp_write_dyb(nor, sec, ASP_DYB_LOCKED);
+ if (ret < 0) {
+ dev_err(nor->dev, "Error locking sector %llx\n", sec);
+ return ret;
+ }
+ debug("%s: Locked sector %llx\n", __func__, sec);
+ }
+ printf("Locked flash sectors %llx-%llx\n", sec_first, sec_last);
+ return 0;
+}
+
+static int asp_unlock(struct spi_nor *nor, loff_t ofs, uint64_t len)
+{
+ int ret;
+ loff_t sec_first, sec_last;
+
+ if (_asp_check_params(nor, ofs, len)) {
+ return -1;
+ }
+ if (!len) {
+ return 0;
+ }
+ sec_first = ofs & ~(nor->sector_size - 1);
+ sec_last = (ofs + len - 1) & ~(nor->sector_size - 1);
+
+ /* Iterate over sectors */
+ for (loff_t sec = sec_first; sec <= sec_last; sec += nor->sector_size) {
+ /* Skip if already unlocked */
+ if (asp_is_unlocked(nor, sec, nor->sector_size)) {
+ debug("%s: sector %llx already unlocked\n", __func__, sec);
+ continue;
+ }
+ /* Unlock the sector */
+ ret = _asp_write_dyb(nor, sec, ASP_DYB_UNLOCKED);
+ if (ret < 0) {
+ dev_err(nor->dev, "Error unlocking sector %llx\n", sec);
+ return ret;
+ }
+ debug("%s: Unlocked sector %llx\n", __func__, sec);
+ }
+ printf("Unlocked flash sectors %llx-%llx\n", sec_first, sec_last);
+ return 0;
+}
+
#endif
static const struct flash_info *spi_nor_read_id(struct spi_nor *nor)
@@ -4570,6 +4722,17 @@ int spi_nor_scan(struct spi_nor *nor)
nor->flash_is_unlocked = sst26_is_unlocked;
}
#endif
+
+#if defined(CONFIG_SPI_FLASH_SPANSION)
+ /* Advanced sector protection */
+ if (info->flags & SPI_NOR_HAS_ASP_LOCK) {
+ log_info("Enabling ASP for %s\n", nor->mtd_name);
+ nor->flash_lock = asp_lock;
+ nor->flash_unlock = asp_unlock;
+ nor->flash_is_unlocked = asp_is_unlocked;
+ }
+#endif
+
#endif
if (info->flags & USE_FSR)
nor->flags |= SNOR_F_USE_FSR;
diff --git a/drivers/mtd/spi/spi-nor-ids.c b/drivers/mtd/spi/spi-nor-ids.c
index 0383175beb5..48ec20d8ab1 100644
--- a/drivers/mtd/spi/spi-nor-ids.c
+++ b/drivers/mtd/spi/spi-nor-ids.c
@@ -374,12 +374,12 @@ const struct flash_info spi_nor_ids[] = {
{ INFO("s25sl064p", 0x010216, 0x4d00, 64 * 1024, 128, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ) },
{ INFO6("s25fl256s0", 0x010219, 0x4d0080, 256 * 1024, 128, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO6("s25fl256s1", 0x010219, 0x4d0180, 64 * 1024, 512, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
- { INFO6("s25fl512s", 0x010220, 0x4d0080, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
+ { INFO6("s25fl512s", 0x010220, 0x4d0080, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR | SPI_NOR_HAS_ASP_LOCK) },
{ INFO6("s25fs064s", 0x010217, 0x4d0181, 64 * 1024, 128, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO6("s25fs128s", 0x012018, 0x4d0181, 64 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO6("s25fs256s", 0x010219, 0x4d0181, 64 * 1024, 512, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO6("s25fs512s", 0x010220, 0x4d0081, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
- { INFO("s25fl512s_256k", 0x010220, 0x4d00, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
+ { INFO("s25fl512s_256k", 0x010220, 0x4d00, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR | SPI_NOR_HAS_ASP_LOCK) },
{ INFO("s25fl512s_64k", 0x010220, 0x4d01, 64 * 1024, 1024, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO("s25fl512s_512k", 0x010220, 0x4f00, 256 * 1024, 256, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ | USE_CLSR) },
{ INFO("s70fs01gs_256k", 0x010221, 0x4d00, 256 * 1024, 512, SPI_NOR_DUAL_READ | SPI_NOR_QUAD_READ) },
diff --git a/include/linux/mtd/spi-nor.h b/include/linux/mtd/spi-nor.h
index 4eef4ab0488..2294a75b420 100644
--- a/include/linux/mtd/spi-nor.h
+++ b/include/linux/mtd/spi-nor.h
@@ -141,6 +141,8 @@
#define SPINOR_OP_BRRD 0x16 /* Bank register read */
#define SPINOR_OP_CLSR 0x30 /* Clear status register 1 */
#define SPINOR_OP_EX4B_CYPRESS 0xB8 /* Exit 4-byte mode */
+#define SPINOR_ASP_DYBRD 0xe0 /* Advanced sector protection - DYB Read */
+#define SPINOR_ASP_DYBWR 0xe1 /* Advanced sector protection - DYB Write */
/* Used for Micron flashes only. */
#define SPINOR_OP_RD_EVCR 0x65 /* Read EVCR register */
--
2.46.1.windows.1
----
